Frame Spark Alloy SL 6011 Integrated Suspension Technology Flex Pivot / Adjustable head angle Syncros Cable Integration System BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork Rock Shox Judy Silver TK Solo Air 15x110mm QR axle / 42mm offset / Tapered Steerer 2-Modes / Reb. Adj. / Lockout / 130mm travel
Rear shock X-Fusion NUDE 5 RLX Trunnion SCOTT custom w. travel / geo adj.3 modes: Lockout-Traction Control-Descend Reb. Adj.Travel 120-80-Lockout / T165X45mm
Remote control SCOTT TwinLoc 2 Technology Suspension & Dropper Remote 3 Suspension modes
Rear derailleur Shimano XT RD-M8100 SGS Shadow Plus / 12 Speed
Shift levers Shimano Deore SL-M6100-R / Rapidfire Plus
Crankset Shimano FC-MT512-155mm CL / 32T
Bottom bracket Shimano BB-MT500 / shell 41x92mm
Chain KMC X12
Cassette Shimano Deore CS-M6100-12 / 10-51 T
Brakes Shimano MT501 Disc
Brake rotor Shimano SM-RT54 CL / F&R 180mm
Handlebar Syncros Fraser 2.0 DC Alloy 6061 D.B.mini Rise / back sweep 8° / 760mm Syncros Pro lock-on grips
Stem Syncros DC 3.0 Syncros Cable Integration System 0° rise / 6061 Alloy / 31.8mm / 1 1/8"
Seatpost Syncros Duncan Dropper Post 2.531.6mm / S & M size 125mm / L & XL size 150mm
Saddle Syncros Tofino 2.5 Regular
Headset Syncros - Acros Angle adjust & Cable Routing HS System+-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
Front hub Shimano HB-MT410-B CL / 15x110mm Syncros 15x110mm
Rear hub Shimano FH-MT410-B CL / 12x148mm / Micro Spline Syncros 12x148mm / Micro Spline
Spokes Stainless Black 15G / 1.8mm
Rim Syncros X-30SE / 32H / 30mm
Front tire Schwalbe Wicked Will / 29x2.4" Performance / TLR / Foldable / Addix
Rear tire Schwalbe Wicked Will 29x2.4" Performance / TLR / Foldable / Addix
Weight in kg (approx.) 14.95 (with tubes)
Weight in lbs (approx.) 32.96 (with tubes)
Total weight 128 kg (Total weight includes the bike, rider, equipment, and potentially additional luggage)
*The manufacturer reserves the right to change website information without notice, including specifications, models, colors, and materials.
*Images are for illustrative purposes only and may not correspond to the product description.
Geometry
