Focus Izalco Max 8.8

Out of stock
SKU: 673012050 Barcode: 4000990452637
Size
€1.917,05 incl. VAT
-51% €3.933,44 €1.917,05 incl. VAT

  • AERO IMPROVEMENTS

    The NACA (National Advisory Committee for Aeronautics) shapes approved in the wind tunnel make our frame highly aerodynamic. At the same time, the frame weighs only 1050 g for the 8.series (size M) with an additional 400 g for the fork. Our C.I.S. hides the cables under the stem. It also comes with an integrated computer mount for both Wahoo and Garmin.

  • 7 SIZES FOR A PERFECT FIT

    IZALCO MAX is available in seven sizes. Combined with the stem, which we offer in six lengths from 70 to 120 mm, it really has all the sizes for each of you.

  • EFFORTLESS HANDLING AND MAXIMUM STIFFNESS

    To help you get that extra power on the road, the bottom bracket is optimized for stiffness and the fork for lateral stiffness. Together with a bold geometry for easier cornering, especially at high speeds, IZALCO MAX is the road bike for all ambitions.

Specifications

FRAME MATERIAL
Carbon

FRAME
Carbon technology frame, disc, BB86, 142x12 mm thru axle, flat mount 160/140 mm, internal cable routing

FORK
MAX technology carbon, integrated cable routing, disc, 100x12 mm, flat mount

GEARSET
Shimano 105 R7100, 12-speed

FRONT DERAILLEUR
Shimano 105 R 7100

REAR DERAILLEUR
Shimano R7100, 12-speed

CASSETTE
Shimano 105 R7100, 12-speed

CHAIN
Shimano Deore CN-M6100, 12-speed

CRANKSET
Shimano 105 R7100

DRIVETRAIN
front: 50/34, rear: 12-34

BOTTOM BRACKET
Shimano Pressfit Road BB86

HANDLEBAR
BBB Basic, aluminium, drop: 125 mm, reach: 70 mm,BBB Basic, aluminium, drop: 125 mm, reach: 70 mm

STEM
FOCUS C.I.S. 2.0 integrated, 31.8 mm, aluminium, with Garmin / Wahoo-Mount

HEADSET
ACROS IS 52/286-IS52/40 (ICR), FOCUS integrated C.I.S.

SADDLE
Selle Royal Groove SRX

SEATPOST
FOCUS Aero Carbon, D-shape, 350 mm, set-back: 15 mm

BRAKES
Shimano 105 R7025

BRAKE LEVER DESCRIPTION
Shimano 105 R7025

BRAKES
Disc

WHEELS
Novatec R4, carbon, 21-622, front: 12x100 mm, rear: 12x142 mm, height: 45 mm

TIRES
Vittoria Rubino TLR, 700 x 28C, Folding

GEARSET
22

WEIGHT OF THE BIKE INCLUDING BATTERY IN KG
8.85 kg
-
* Subject to technical changes without notice. Errors and omissions excepted.
** Weight in size M, standard specifications and without pedals.
-

GEOMETRIES

XXS XS S M L XL XXL
DIMENSION (MM) 47 50 52 54 56 58 61
SIZE 470 500 520 540 560 580 610
HANDLEBAR WIDTH (MM) 400 400 400 420 420 420 440
STEM LENGTH 80 90 100 110 110 120 120
CRANK LENGTH (MM) 165 165 170 172.5 172.5 175 175
VERTICAL TUBE LENGTH 360 360 360 360 360 360 360
A SEAT TUBE LENGTH 455 475 495 515 535 555 585
B TOP TUBE LENGTH 505 517 530 543 568 582 607
C STEERING ANGLE (MM) 70 71 72 72.5 72.5 73 73
D SEAT TUBE ANGLE (MM) 75 74.5 74 73.5 73.5 73 73
E REAR STAY LENGTH 410 410 410 410 410 410 410
F BOTTOM BRACKET HEIGHT 72 72 72 72 72 72 72
G STEERING TUBE LENGTH 90 100 115 135 155 175 195
H FORK HEIGHT 371.5 371.5 371.5 371.5 371.5 371.5 371.5
I FORK PRELOAD 46 46 46 46 46 46 46
J STEP 975 976 975 979 1004 1008 1033
K STACK 500 513 531 552 571 592 611
L REACH 370 375 378 380 399 401 420
